Coriolis Mass Flowmeter
Flowtel Engineering Series FECMF Model Coriolis Mass Flow meter is based on the Coriolis effect. It can directly measure the mass flow of the fluid flowing inside the closed tube with high measurement accuracy. The measuring tube has a very low vibration, which can be regarded as an inactive component. It is a popular and very high-precision flow measuring instrument with no obstructions or moving parts in the measuring line. Coriolis force, the core parameter of a mass flow meter, refers to the force exerted by a body moving in a straight line in a rotating system.
Coriolis Mass Flowmeter
Code: CMFM-FL, Model: FECMF
Flowtel Engineering Series FECMF Model Coriolis Mass Flow meter is based on the Coriolis effect. It can directly measure the mass flow of the fluid flowing inside the closed tube with high measurement accuracy. The measuring tube has a very low vibration, which can be regarded as an inactive component. It is a popular and very high-precision flow measuring instrument with no obstructions or moving parts in the measuring line. Coriolis force, the core parameter of a mass flow meter, refers to the force exerted by a body moving in a straight line in a rotating system.
Product Details
Features
➢ Display several parameters simultaneously such as Mass Flow, Density & Temperature of the medium
➢ High Measurement Accuracy ranging from 0.1%-0.5%
➢ Wide Application: Besides common fluid, a mass flowmeter can also measure fluids such as non-newtonian fluid, all kinds of slurry etc
➢ Installation without choosing an upstream or downstream pipe while installing in horizontal pipeline & if the instrument installed in vertical pipeline, the fluid is required to pass through flowmeter from bottom to top
➢ Safe & reliable operation, free on-site maintenance
➢ No different sensors are required to measure various fluids, only one single is sufficient
➢ Can be connect to the batch controller, Ideal for batching and loading with empty-full-empty applications
➢ Excellent repeatability
Specification
| Measuring Media | Liquids & Slurries |
| Measuring Caliber | DN3 - DN150 |
| Connection Mode | Flange & Threaded |
| Measurement Accuracy | 0.1%, 0.15%, 0.2%, 0.5% |
| Pressure Grade | 40Bar, 100Bar, 160Bar, 250Bar |
| Range Ratio | 40Bar, 100Bar, 160Bar, 250Bar, 420Bar; 150LB, 300LB, 600LB |
| Medium Temperature | -50°C - 300°C |
| Ambient Temperature | Sensor : -40°C - 65°C, Converter : -15-55°C |
| Transmitter Power Supply | Less than 2W |
| Overall Power Consumption | DC 18-36V or AC 85-220V |
| Output Signal | 4-20mA, RS485, Modbus & HART(Optional) |
| Frequency Rate | 0-10 KHz |
| Alarm | IP65 Standard |
| Protection Grade | Optional (1-2 Alarm, 10A/220V/AC, 5A/30V/DC) |
| Explosion Proof Grade | Exd[ib]IICT6 |
| Measuring Tube Material | SS316L, Titanium & Hastelloy C |
Application
Oil & Gas, Marine, Power, Chemical, Power, Paper
Line Size Selector Chart with respect to flowrange & working pressure
