METAL TUBE ROTAMETER

For higher pressures and temperatures beyond the practical range of glass tubes, metal tubes are used. These are usually manufactured in stainless steel. The position of the float is determined by magnetic or mechanical followers that can be read from the outside of the metal metering tube. Similar to glass tube rotameters, the spring-andpiston combination determines the flowrate, and the fittings and materials of construction must be chosen so as to satisfy the demands of the applications. These meters are used for services where high operating pressure or temperature, water hammer, or other forces would damage glass metering tubes. Spring and piston flowmeters can be used for most fluids, including corrosive liquids and gases. They are particularly well suited for steam applications, where glass tubes are unacceptable.
